PAI Send Mode Under Gateway Settings - Anyone Got It to Work?

voipexpert · February 6, 2025, 2:13pm

Hey everyone,

I’m trying to configure my gateway settings in Yeti Switch to send an Asserted Identity (PAI) in the SIP INVITE. Under Translations settings, I selected:

PAI Send Mode → Build SIP URI from Source Number

However, for some reason, it’s not working as expected. Has anyone successfully used this setting? If so:

Did you need to adjust any additional settings on the gateway?
Were there any SIP header modifications required?
Did it work out of the box for you, or did you face similar issues?

I’d really appreciate any insights or troubleshooting tips!

Thanks in advance!

dmitry.s · February 6, 2025, 5:07pm

what version you running?

voipexpert · February 7, 2025, 9:03am

Hi Dmitry, the vesion is 1.13.8. Routing 20250115133012. CDR 20241219145036.

dmitry.s · February 7, 2025, 10:05am

have you set PAI DOMAIN ?

voipexpert · February 10, 2025, 11:32pm

Yes I have set a domain!

P.S. I have also updated to the latest version 1.13.9. Routing 20250115133012. CDR 20241219145036.

dmitry.s · February 11, 2025, 9:44am

check documentation please

voipexpert · February 11, 2025, 2:38pm

I did study documentation very well, and have try in many ways around by the way and still trying to get it to work.

dmitry.s · February 11, 2025, 2:41pm

PAI Send Mode = Build SIP URI from Source Number
PAI Domain = sip...

Should work

voipexpert · February 12, 2025, 9:47am

Thank you, I have managed to get it to work, here are the settings I got on my end.

Indeed I was able to get to a result of inserting a P-Asserted-Identity: into invite, but not the Diversion header.
